YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine
  • YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine

YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine

Place of Origin Shanghai, China
Brand Name YIMU
Certification CE
Model Number CM100
Product Details
Type:
Capping Machine
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory
Showroom Location:
Canada, United States, Viet Nam, Chile, Australia
Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Warranty Of Core Components:
5 Years
Core Components:
PLC, Motor
Condition:
New
Application:
Food, Beverage, Commodity, Chemical, Medical
Driven Type:
Electric
Automatic Grade:
Automatic
Voltage:
220V
Packaging Type:
Case
Packaging Material:
Wood
Dimension(L*W*H):
2000*1300*2000mm
Weight:
450 KG
Warranty:
2 Years
Key Selling Points:
High Safety Level
Product Name:
Automatic Whisky Wine Glass Bottle ROPP Cap Aluminum Capping Machine
Capping Speed:
30-40bottles/min
Function:
Screwing Pressing Caps
Cap Diameter:
10- 150 Mm
Capping Type:
Screw Plastic Cap
Bottle Height:
50-300mm
Suitable For:
Aluminum Plastic Sealing
Advantage:
Full Automatic
After-sales Service Provided:
Video Technical Support Online Support
Usage:
ROPP Capping Machine
Port:
Shanghai
High Light:

Aluminum Screw Capper

,

Wine Bottle Ropp Screw Capper

,

Olive Oil Bottle Screw Capping Machine

Payment & Shipping Terms
Minimum Order Quantity
1SET
Price
$7,300.00/sets 1-2 sets
Packaging Details
automatic whisky wine glass bottle ROPP aluminum capper sealing syrup bottle screw capping machine
Supply Ability
500 Set/Sets per Year
Product Description
PRODUCTS DESCRIPTION
CM100 Automatic ROPP Cap Screwing Machine
This Machine is autoamtic feeding cap and screwing cap, it stuiable for all kinds of round size ROPP cap, it can connect with other machine covneyor, for automatic running machine. machine loading lid automatic, and feed lid onto container mouth, customized capping head automatic catch cap from cap path. Capping head use servo motor to screw cap by torsion, easy to control tigthen. after capping, moving container to other machines.
Normal, the machine suitable for glass bottle and aluminium cap, such as wine bottle, olive oil bottle, syrup bottle,whisky bottle and so on.

APPLICATION
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 0
PRODUCT PARAMENTERS
1
Applied bottle height
60-400mm
2
Applied bottle width (diameter)
50-150mm
3
Applied cap diameter
15-72mm
4
Success rate of capping
>99.99%
5
Power supply
1500W, 110V/220V, 50/60Hz, 1 phase (customized)
6
Speed control
Frequency conversion adjusting speed
7
Machine size
L2000 * W1000 * H2000 mm
8
Machine net weight
500KG
9
Cap feeding device
Optional (cap elevator or vibrating disk)
10
Machine capacity
1000-2500 bottles/hour
MAIN CONFIGURATION LIST
PLC
SIEMENS / Mitsubishi
HMI
SIEMENS / WEINVIEW
Sensor
SICK / KEYENCE / Panasonic
Motor
Taiwan Taibang
Servo motor
China Raynen
Frequency changer
Taiwan Delta
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 1
DETAILS IMAGES
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 2
CUSTOMER
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 3

COMPANY PROFILE

YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 4
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 5
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 6
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 7
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 8
YIMU-CM100 Wine Bottle Ropp Screw Capper Olive Oil Bottle Aluminum Screw Cap Sealing Machine 9
YIMU machinery is a professional manufacturer of packaging machinery in China, and. It integrating R&D, manufacture, distribution and after-sale service. With nearly two decades of development, we have been congregating talents of Machine manufacturing industry and keep ahead in researching and developing. Until now, our products are widely used throughout the pharmaceutical, chemical, food, and agricultural chemical industries. Most of them have been great sold to the Asia, Africa, Europe and America, and obtained great popularity because of their high quality and competitive price. MODERN DESIGNS YIMU machinery engineers are constantly working to modernize and simplify our designs giving our customers the competitive edge for the most efficient, technologically advanced filling line and end of packaging line. Our diverse line of packaging equipment is engineered for products in the food, pharmaceutical, cosmetic, chemical and specialty industries. All of our packaging machinery is constructed from the highest quality materials with the highest quality workmanship. We strongly work with many famous suppliers for latest technologies in PLC Controller, electric components and pneumatics to ensure the equipment operation with high efficiency and quality. CUSTOM OPTIONS If you have unique packaging equipment requirements such as liquid filling line, end of packaging line, please feel free to contact us and we can customize our packaging machinery to accommodate your product and even work with your existing packaging line. Once we evaluate your packing requests, our experienced staff will discuss the wide range of packaging equipment options available. Then we will consult with you to determine what packaging machinery best suits your needs and budget. TECHNICAL SUPPORT AND CUSTOMER SERVICE Qualified, skilled technicians are available for trouble shooting and problem solving to ensure your production line is up and running smoothly. All of our packaging equipment includes a one-year warranty. Extended warranties are also available. Most replacement parts are stocked and they can be shipped within 24 hours of your on requests.
