Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
  • Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle
Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle

Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle

Place of Origin Shanghai
Brand Name YIMU
Certification CE
Model Number CM200
Product Details
Product Name:
Popular Automatic Wine Glass Jar Syrup Round Bottle ROPP Aluminum Screw Capping Machine
Function:
ROPP Capping Machine
Bottle Type:
Glass Bottle
Cap:
Aluminum ROPP Cap
Material:
SUS304
Capping Speed:
25-45 Bottles/min
After-sales Service Provided:
Online Video Technical Support,Free Spare Parts
Driven Type:
Pneumatic, Electric
Application:
Wine, Pharmacy
Warranty:
1-2 Years
Highlight:

Pneumatic Automatic Capping Machine

,

ROPP Screw Automatic Capping Machine

,

ROPP Screw Capping Machine

Payment & Shipping Terms
Minimum Order Quantity
1set
Price
Negotiable
Packaging Details
wooden case, L2000*W800*H1700mm, 300KG
Delivery Time
12-15 working days
Payment Terms
T/T, L/C, D/A, Western Union
Supply Ability
20set/month
Product Description

Popular Automatic Wine Glass Jar Syrup Round Bottle ROPP Aluminum Screw Capping Machine



Cap chute features
• All contact parts in stainless steel.
• Designed and tested for each cap to avoid jamming.
• Includes cap demand sensor to start and stop the cap feeder.
• Quick change over, since parts are pin guided so no tweaking is required.
Vibratory cap feeder features
• Aluminum casting with polyurethane liner to minimizes cap marking-scratching
• 24 inch diameter feeding disc - ramp assembly.
• Bad caps rejected mechanically, minimum air usage.
• Cap by demand controlled by photoelectric sensor.
• Bowl tooled for one model cap.
• Adjustable vibration and speed control
• Heavy duty extra heavy base for better vibration transmission.
• Sorter mounted on machine, no need for independent height adjustment.
Capper features
• Machine designed to place and form metal caps on a wide range of containers – enclosures.
• Price includes one set of change of parts (star wheel, outer guide and cap delivery).
• Bottle will pick up cap and the container will be indexed into position.
• Maximum bottle diameter with 12 pocket star wheel: 4.25 in
• Maximum bottle diameter with 6 pocket star wheel: 8.00 in
• Automatic start and stop with presence or absence of containers.
• Jamming clutches with electric signal for shutdown on product jamming (This prevents major damage to parts and minimizes possible spills).
Electrical box
• Ac motor with frequency drive speed control
• Stainless steel electric enclosure.
• Heavy duty 304 Stainless steel welded frame.
• Stainless steel enclosure with polycarbonate windows and safety switches.
• Gear driven transmission machine to avoid timing loss.
• Complete height adjustment with bottle setting guide for quick changeovers.
• Tool less changeovers for star wheels and most change parts.
Technical Parameter:

Cap feeding device
Vibration disk
Capping type
ROPP capping head screwing
Bottle height
60-300mm
Cap diameter
16-68mm
Bottle diameter
50-100mm
Capping speed
25-50 bottles/min
Capping voltage
AC 220V 50/60Hz,1 phase, (customized)
Air pressure
0.3-0.6MPa
Dimension
2000(L)*1000(W)*2000(H)mm
Packing size
2100(L)*1100(W)*1700(H)mm
Machine weight
About 500KG



Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle 0

Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle 1Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle 2Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle 3



Pneumatic ROPP Screw Automatic Capping Machine For Wine Glass Bottle 4
